Powered by SoftRAID (SoftRAID software option only). Add your own drives! Thunderbolt 3 cable included.
Highlights
- Two Thunderbolt 3 ports
- Dedicated DisplayPort 1.2 port
- Up to 1550MB/s sustained performance1
- Includes SoftRAID: robust software for creating, monitoring, and managing advanced RAID sets
- Four hot-swappable universal drive bays: mix or match 2.5-inch (no adapter needed) and 3.5-inch HDDs and SSDs
- Ultra quiet, heat dissipating aluminum chassis
The Speed You Need
All New Design for Power and Performance
ThunderBay 4, OWC's flagship 4-bay RAID powerhouse is bigger and faster than ever before. Now with the unbelievable performance of Thunderbolt 3 up to 1550MB/s sustained performance1it's the ultimate workhorse external storage solution. Not only faster, the new ThunderBay 4 Thunderbolt 3 is now natively compatible with both 2.5" and 3.5" drives, and with a redesigned chassis, it's even cooler and quieter too.
Edit, Experiment, Create, Design
Designed with performance in mind and engineered to harness the power of Thunderbolt 3, ThunderBay 4 is an incredibly flexible external solution with the throughput to support multi-stream compressed 4K video and other bandwidth-intensive operations. ThunderBay 4 is highly configurable to perfectly match your performance needs. Choose between traditional hard drives or Solid State Drives. Use each drive independently, or in the RAID configuration of your choice for the optimal balance of performance and data-redundancy. Get the most out of your storage, take the brakes off your workflow, and do more with a ThunderBay 4.
Includes SoftRAID XT: Easy and Complete Drive Management
SoftRAID XT is the most powerful, intuitive software RAID utility on the market. Multiple RAID levels let you select the RAID level that fits you or your project’s needs best. If you need maximum volume capacity, optimum drive performance, data protection, or a combination of attributes, SoftRAID has you covered.
Packed with features like drive validation, verification and failure prediction—SoftRAID includes features you simply don’t get with hardware RAID. It’s like having a datacenter on your desktop! From home users looking to protect photos and documents to professionals needing to protect and quickly access projects, SoftRAID is the perfect solution.
Compatible: Works with macOS 14.x Sonoma, M series Macs and Windows 11
Advanced: Create RAID 0/1/4/5/1+0 (10) with Macs, RAID 0/1 with Windows machines
Protected: SoftRAID Monitor constantly watches your disks and alerts you if problems are detected
Validated: Volume validation ensures sectors can be read and parity is correct
Certified: Checks disks before use to ensure they are safe for data storage
Vigilant: Error prediction helps protect against unexpected failure
Universal: Move SoftRAID arrays seamlessly between Macs and PCs with built-in OWC MacDrive technology
SoftRAID provides a level of performance that you simply can’t get with hardware RAID. Learn more about the power of SoftRAID XT.
Certified and Tested
Each ThunderBay 4 solution undergoes OWC's multi-hour drive "burn-in" performance certification procedure prior to shipping. This ensures your ThunderBay 4 arrives operating properly, ready for demanding use.
4 drive bays plus so much more. Time-tested Cooling
Built on OWC's time-tested enclosure cooling technology, ThunderBay 4 utilizes an open "flow-thru" vented design with an oversized 92 mm, low-turbulence, noise-quieting fan to keep the drives running cool and reliably.
Multi-Drive
Daisy-chain up to six ThunderBay 4s for massive storage capabilities and increased performance, or connect multiple ThunderBay 4s to multiple Thunderbolt 3 ports to achieve exponential speed capabilities.
Vibration Dampened
ThunderBay 4's drive isolating design reduces sonic resonance, and is aided by over-sized, rugged, vibration-absorbing, non-skid feet.
DisplayPort 1.2 Support
Dual Thunderbolt 3 ports let you connect the display of your choice that your computer can support, including 4K displays.
SoftRAID XT works with macOS 10.12 or later and Windows 10. M1 Macs require macOS 11.3 or later. SoftRAID is licensed per computer.
Includes
- (1) OWC ThunderBay 4 External Storage Enclosure
- (1) 0.7M (28") Thunderbolt Cable
- (1) US Power Cable
- (2) Security Keys for Front Panel Lock
- (1) Quick Start Guide for OWC ThunderBay 4 with Thunderbolt 3
- (1) Assembly Manual & User Guide for OWC ThunderBay 4 with Thunderbolt 3
- 1 Year OWC Limited Warranty
- Number of Bays: 4
- Drive Bays: 4 bays supporting: 2.5-inch SATA drives, 3.5-inch SATA drives
- Plug and Play: Yes
- Hot Swap Support: Yes
- Boot Support: Boot Camp is not supported.
- RAID Capable: Yes
- RAID Levels Supported: JBOD
- RAID Features: Software RAID
- Power Delivery: Thunderbolt 3 host port provides up to 15W of power to the host computer. Thunderbolt 3 device port (for external drives and other devices) provides 15W of power.
-
Device Ports:
- (1) Host Port - Thunderbolt 3 (USB-C) up to 40 Gb/s (5000 MB/s)
- (1) Thunderbolt 3 (USB-C) Port
- Data Transfer Rate (Maximum): Thunderbolt 3: Up to 40 Gb/s (or 5000 MB/s)
-
Chipset / Controller:
- SATA Controller: (2) ASM1062
- Thunderbolt 3: (1) Intel DSL6540
- Host Interface Requirements: Thunderbolt (USB-C) port (backward compatible with Thunderbolt 2/Thunderbolt1)
- External Power Adapter: No
- Power Supply: Internal UL-listed universal auto-switching power supply
- Need an additional power supply? Secondary/replacement power supplies are also available.
- AC Input: 100-230V
- Replacement Adapter Part Number: OWCMNEPWR3PUS (sold separately)
- Cooling: (1) 92mm cooling fan
- Security Slot: Yes
- Power Button: Yes
- Power/Activity LED: Yes
- Housing Color: Black
- Housing Material: Aluminum
- Dimensions: Height: 17.7 cm (7.0 in), Length: 24.5 cm (9.6 in), Width: 13.5 cm (5.3 in)
- Weight: 3.9 kg (8.60 lbs)
- Reach Certification: Yes
- Country of Origin: Taiwan
- TAA Compliance: Yes
- Ambient Temperature: Operating: 50°F to 95°F (10°C to 35°C), Non-Operating: -40°F to 149°F (-40°C to 65°C)
- Humidity: Operating: 8% to 90% non-condensing, Non-Operating: 5% to 95% non-condensing
- Thunderbolt 2/Thunderbolt compatibility: requires a certified Thunderbolt 3 (USB-C) to Thunderbolt 2 (mDP) adapter and a Thunderbolt 2 cable (available separately). This configuration provides data transfer at up to 20Gb/s but does not support notebook charging.
- For units purchased prior to 12/24/18, please see the OWC ThunderBay 4 Support Page for instructions on how to update your ThunderBay's firmware.
-
Mac OS Compatibility:
- macOS 10.14 Mojave
- macOS 10.15 Catalina
- macOS 11.x Big Sur
- macOS 12.x Monterey
- macOS 13.x Ventura
- macOS 14.x Sonoma
-
PC OS Compatibility:
- Windows 10 64-bit Edition
- Windows Server 2022
- Windows 11
-
Compatible Mac Models:
-
iMac
- iMac | 2017 iMac18,1 - A1418 - EMC3068
- iMac | 2017 iMac18,2 - A1418 - EMC3069
- iMac | 2017 iMac18,3 - A1419 - EMC3070
- iMac | 2019 iMac19,1 - A2115 - EMC3194
- iMac | 2019 iMac19,2 - A2116 - EMC3195
- iMac | 2020 iMac20,1 - A2115 - EMC3442
- iMac | 2020 iMac20,2 - A2115 - EMC3442
- iMac | 2021 iMac21,1 - A2438 - EMC3663 - M1
- iMac | 2021 iMac21,2 - A2439 - EMC3664 - M1
- iMac | 2023 Mac15,4 - A2874 - EMC8207 - M3
- iMac | 2023 Mac15,5 - A2873 - EMC8206 - M3
-
iMac Pro
- iMacPro | 2017 iMacPro1,1 - A1862 - EMC3144
-
MacBook Air
- MacBookAir | 2018 MacBookAir8,1 - A1932 - EMC3184
- MacBookAir | 2019 MacBookAir8,2 - A1932 - EMC3184
- MacBookAir | 2020 MacBookAir9,1 - A2179 - EMC3302
- MacBookAir | 2020 MacBookAir10,1 - A2337 - EMC3598 - M1
- MacBookAir | 2022 Mac14,2 - A2681 - EMC4074 - M2
- MacBookAir | 2023 Mac14,15 - A2941 - EMC8301 - M2
- MacBookAir | 2024 Mac15,12 - A3113 - EMC8611 - M3
- MacBookAir | 2024 Mac15,13 - A3114 - EMC8612 - M3
-
MacBook Pro
- MacBookPro | 2016 MacBookPro13,1 - A1708 - EMC2978
- MacBookPro | 2016 MacBookPro13,2 - A1706 - EMC3071
- MacBookPro | 2017 MacBookPro13,3 - A1707 - EMC3072
- MacBookPro | 2017 MacBookPro14,1 - A1708 - EMC3164
- MacBookPro | 2017 MacBookPro14,2 - A1706 - EMC3163
- MacBookPro | 2017 MacBookPro14,3 - A1707 - EMC3162
- MacBookPro | 2018 MacBookPro15,1 - A1990 - EMC3215
- MacBookPro | 2018 MacBookPro15,2 - A1989 - EMC3214
- MacBookPro | 2018 MacBookPro15,3 - A1990 - EMC3215
- MacBookPro | 2019 MacBookPro15,1 - A1990 - EMC3359
- MacBookPro | 2019 MacBookPro15,2 - A1989 - EMC3358
- MacBookPro | 2019 MacBookPro15,3 - A1990 - EMC3359
- MacBookPro | 2019 MacBookPro15,4 - A2159 - EMC3301
- MacBookPro | 2019 MacBookPro16,1 - A2141 - EMC3347
- MacBookPro | 2019 MacBookPro16,4 - A2141 - EMC3347
- MacBookPro | 2020 MacBookPro16,2 - A2251 - EMC3348
- MacBookPro | 2020 MacBookPro16,3 - A2289 - EMC3456
- MacBookPro | 2020 MacBookPro17,1 - A2338 - EMC3578 - M1
- MacBookPro | 2021 MacBookPro18,1 - A2485 - EMC3651 - M1 Pro
- MacBookPro | 2021 MacBookPro18,2 - A2485 - EMC3651 - M1 MAX
- MacBookPro | 2021 MacBookPro18,3 - A2442 - EMC3650 - M1 Pro
- MacBookPro | 2021 MacBookPro18,4 - A2442 - EMC3650 - M1 Max
- MacBookPro | 2022 Mac14,7 - A2338 - EMC8162 - M2
- MacBookPro | 2023 Mac14,10 - A2780 M2 Pro
- MacBookPro | 2023 Mac14,5 - A2779 M2 Max
- MacBookPro | 2023 Mac14,6 - A2780 M2 Max
- MacBookPro | 2023 Mac14,9 - A2779 M2 Pro
- MacBookPro | 2023 Mac15,10 - A2992 - EMC8407 - M3 Max
- MacBookPro | 2023 Mac15,11 - A2991 - EMC8408 - M3 Max
- MacBookPro | 2023 Mac15,6 - A2992 - EMC8407 - M3 Pro
- MacBookPro | 2023 Mac15,3 - A2918 - EMC8304 - M3
- MacBookPro | 2023 Mac15,7 - A2991 - EMC8408 - M3 Pro
- MacBookPro | 2023 Mac15,8 - A2992 - EMC8407 - M3 Max
- MacBookPro | 2023 Mac15,9 - A2991 - EMC8408 - M3 Max
-
Mac Pro
- Mac Pro | 2019 MacPro7,1 - A1991 - EMC3203
- Mac Pro | 2023 Mac14,8 - A2786 - EMC8163 - M2 Ultra
- Mac Pro Rack | 2019 MacPro7,1 - A2304 - EMC3413
- Mac Pro Rack | 2023 Mac14,8 - A2787 - EMC8164 - M2 Ultra
-
Mac Studio
- Mac Studio | 2022 Mac13,1 - A2615 - EMC3988 - M1 Max
- Mac Studio | 2022 Mac13,2 - A2615 - EMC3988 - M1 Ultra
- Mac Studio | 2023 Mac14,14 - A2901 - EMC8292 - M2 Ultra
- Mac Studio | 2023 Mac14,13 - A2901 - EMC8292 - M2 Max
-
Mac Mini
- Macmini | 2018 Macmini8,1 - A1993 - EMC3213
- Macmini | 2020 Macmini9,1 - A2348 - EMC3569 - M1
- Macmini | 2023 Mac14,3 - A2686 - EMC8003 - M2
- Macmini | 2023 Mac14,12 - A2816 - EMC8180 - M2 Pro
-
PC Compatible: Yes (PC must have a compatible Thunderbolt port)
-
iMac
Bought this raid device to replace my Drobo 5D3. Obviously quicker with the thunderbolt 3 ports. As quiet as the old one. Only time will tell if it’s as robust as the Drobo but I’m pleased. Setup with softraid XT is very easy as is prepping the new 6Tb hard drives
