- Samsung 9100 PRO PCIe 5.0 NVMe SSD – Up to 14,800MB/s, Gen5, 1–8TB Samsung 9100 PRO PCIe 5.0 NVMe SSD – Up to 14,800MB/s, Gen5, 1–8TB
- Description
- Specifications
- Compatibility
- Product videos
- Reviews
Step into the future of storage performance with the Samsung 9100 PRO PCIe® 5.0 NVMe SSD. Built for gamers, creators, and power users, it delivers blistering up to 14,800MB/s read and 13,400MB/s write speeds—double the throughput of Gen4-class drives like 990 PRO. With random performance up to 2,200K / 2,600K IOPS, it tears through huge game assets, 8K timelines, complex 3D scenes, and AI workloads with ease.
Thanks to an advanced 5nm controller and refined thermal design, 9100 PRO boosts power efficiency by up to 49% while sustaining peak speed under pressure. Choose capacities up to 8TB to keep entire game libraries, footage, and datasets on a single ultra-fast volume. Fine-tune and protect your drive with Samsung Magician — performance optimization, secure data migration, firmware updates, and health monitoring in one place.
Whether you’re chasing higher FPS, smoother edits, or faster AI iteration, 9100 PRO is the Gen5 platform that keeps you ahead.
Highlights
- PCIe® 5.0 performance: up to 14,800/13,400MB/s sequential read/write
- Next-gen responsiveness: up to 2,200K / 2,600K random IOPS for heavy multitasking & AI
- Power & thermals: up to 49% better efficiency with advanced thermal control
- Creator & gamer ready: instant loads, smooth 8K edits, rapid asset ingest
- Mega capacity: options up to 8TB for massive projects and libraries
- Magician software: optimize, migrate, update, and monitor with Samsung Magician
What’s in the Box
- Samsung 9100 PRO PCIe® 5.0 NVMe SSD
- Quick Start Guide / Documentation
- Interface: PCIe® 5.0 x4, NVMe™ 2.0
- Sequential Read: Up to 14,700 MB/s (performance may vary by system configuration)
- Sequential Write: Up to 13,300 MB/s (performance may vary by system configuration)
- Random Read: Up to 1,850,000 IOPS (performance may vary by system configuration)
- Random Write: Up to 2,600,000 IOPS (performance may vary by system configuration)
- Warranty: 5-Year Limited or 600TBW Limited (whichever occurs first)
- Application: Client PCs, Game Consoles
- Weight: Max 9.0 g
- Dimensions (W × H × D): Max 80.15 × 22.15 × 2.38 mm
- Capacity Options: 1TB, 2TB, 4TB, 8TB
- TRIM Support: Supported
- S.M.A.R.T. Support: Supported
- GC (Garbage Collection): Auto GC Algorithm
- Encryption: AES 256-bit (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)
- WWN Support: Not supported
- Device Sleep Mode: Yes
- Average Power (System Level): Read 7.6 W / Write 7.2 W (typical; varies by system)
- Idle Power: Typical 4 mW
- Device Sleep Power: Typical 3.3 mW
- Allowable Voltage: 3.3 V ± 5%
- Reliability (MTBF): 1.5 Million Hours
- Operating Temperature: 0 – 70 °C
- Shock: 1,500 G, 0.5 ms (Half-sine)
- Management Software: Samsung Magician
- Product Flyer: 1TB / 2TB / 4TB / 8TB
- Systems: Computers with an M.2 slot that supports NVMe SSD PCIe 5.0 x4 (backward compatible with PCIe 4.0 x4)
- Adapter Cards: Compatible with PCIe M.2 SSD carrier cards that support NVMe PCIe 5.0/4.0 x4
