M.2 SSD 600S
Transcend's SATA III 6Gb/s M.2 SSD 600S boasts ultra-compact dimensions to address the high-performance needs and strict size limitations of small form factor devices, best suited for Ultrabooks and thin, light notebooks. Featuring a powerful controller, exceptional transfer speeds, and MLC NAND flash memory, the M.2 SSD 600S easily handles everyday computing tasks as well as demanding multimedia applications, delivering steadfast reliability.
MLC NAND flash inside
Transcend's M.2 SSD 600S is manufactured with reliable, top-tier MLC NAND flash memory to ensure superior stability and endurance, making it well-suited to high-end applications.
Perfect for your Ultrabook
Compliant with all M.2 form factors from Type 2242, 2260, to 2280, Transcend's MLC M.2 SSDs are perfect for use in Ultrabooks and lightweight notebooks. Measured at just 60mm in length, the M.2 SSD 600S makes for an easy upgrade to your computer, taking up little space while giving it a much-needed energy boost.
Superior transfer speeds
Featuring the M.2 standard (60mm), the next-generation SATA III 6Gb/s interface and a powerful controller, Transcend's M.2 SSD 600S reaches incredible read and write speeds of up to 530MB/s and 400MB/s. When used as a cache, the M.2 SSD 600S provides 1.5 times faster boot time than conventional hard drives.
Trusted endurance. Steadfast reliability.
Transcend's M.2 SSD 600S offers great Terabytes Written (TBW) values (up to 740 TB) indicating the total amount of data you can write into the drive over its lifetime. You can count on the drive to stay reliable even under an intensive workload.
Store more in less space
The M.2 form factor enables expansion and integration of functions onto a single form factor module solution. M.2 SSDs include a smaller form factor but with larger capacities than that of mSATA and half-slim SSDs.
Potent and feature-laden
Despite its extra-small dimensions, the M.2 SSD 600S boasts a DDR3 DRAM cache and contains advanced features to enhance the performance of the SSD.
SSD Scope software
Transcend SSD Scope is advanced, user-friendly software that makes it easy to ensure your Transcend SSD remains healthy and continues to run fast and error-free by determining the condition and optimizing the performance of your drive. Download here
Guaranteed quality
Transcend’s solid-state drives are built to the highest standards and rigorously tested, and offer outstanding quality, performance, and reliability.
-
Appearance
- Dimensions: 60.0 mm x 22.0 mm x 3.58 mm (2.36" x 0.87" x 0.14")
- Weight: 7 g (0.25 oz)
- M.2 Type: 2260-D2-B-M (Double-sided)
-
Interface
- Bus Interface: SATA III 6Gb/s
-
Storage
- Flash Type: MLC NAND flash
- Capacity: 128 GB/256 GB
- Manufacturer part numbers: TS128GMTS600S/ TS256GMTS600S
-
Operating Environment
- Operating Temperature: 0°C (32°F) ~ 70°C (158°F)
- Operating Voltage: 3.3V±5%
-
Performance
- Sequential Read/Write (CrystalDiskMark): 256GB 530/400 MB/s; 128GB 530/200 MB/s
- 4K Random Read/Write (IOmeter): 256GB 70,000/70,000 IOPS; 128GB 70,000/50,000 IOPS
- Terabytes Written (TBW): 256GB 740 TBW; 128GB 360 TBW
- Mean Time Between Failures (MTBF): 2,000,000 hour(s)
- Drive Writes Per Day (DWPD): 2.5 (3 yrs)
-
Note
- 1. Speed may vary due to host hardware, software, usage, and storage capacity.
- 2. The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
-
Warranty
- Certificate: CE/FCC/BSMI/KC/RCM
- Warranty: Three-year Limited Warranty
-
System Requirement
- Operating System: Microsoft Windows 7; Microsoft Windows 8; Microsoft Windows 10; Linux Kernel 2.6.31 or later
- Note: Please make sure that your computer has an M.2 slot.
-
Technology
- TRIM & NCQ Command: Yes
- S.M.A.R.T.: Yes
- DDR3 DRAM Cache: Yes
- Advanced Garbage Collection: Yes
- DevSleep Mode: Yes
- RAID Engine: No
- LDPC Coding: No
- Data Sheet: PDF
- Compatible with all M.2 SATA form factors type 2260 laptops, All in One PCs, and other devices.
